News | July 16, 2012

Sinusoid Pty Ltd Introduces Rotary Encoders - RPE1, RPE2

SYDNEY--(BUSINESS WIRE) --

Sinusoid Pty Ltd announces the release of its new rotary encoders, RPE1 and RPE2. The encoders offer continuous monitoring of rotation angle for speeds of up to 7500rpm. Applications include CNC, process control, consumer electronics and robotics.

Models RPE1 and RPE2 are magnetically coupled, hall-effect rotary encoders, which differ in their output format.

The RPE1 provides absolute analog output of a voltage that is directly proportional to the angle of the shaft, increasing linearly for a clockwise direction. Output range is 0-100% of supply voltage.

The RPE2 features dual outputs of incremental quadrature, and absolute PWM with index channel. The quadrature channels A and B are out of phase by 90° depending on rotation direction. The PWM channel has 1024 positions.

All models provide 10-bit output resolution.

Both RPE1 and RPE2 models are available with shaft sizes of either 8mm or 6.35mm (¼”) diameter.

The encoders are robustly constructed in anodised aluminium, and have dual 8mm ID ball bearings for shaft support. Body dimensions are 31x30mm diameter and mounting is by flange mount with 3 x M3 screws.

RPE models are suitable for maximum speeds of up to 7500rpm depending on ingress protection required.

Mark Vitnell, Director of Sinusoid Pty Ltd says “These new RPE encoders are quality products, made in Australia at a competitive price”.

Typical applications are:



Digital potentiometers











CNC Machine tool position



Valve angle sensor











Hand and Jog wheel encoders



Lever angle











Tool control



Industrial actuator position











Gearbox speed sensor



Motor speed sensor











Conveyors



Robotics encoder











Antenna position indicator



Front panel switch











Accelerator control



Control position indicator











Controls for video and audio



Rotary position sensing













mixing and editing

Part numbers:

RPE1-8



Absolute analog rotary encoder with 8mm shaft

RPE1-635



Absolute analog rotary encoder with 6.35mm (¼”) shaft

RPE2-8



Absolute PWM and incremental quadrature rotary encoder with 8mm shaft

RPE2-635



Absolute PWM and incremental quadrature rotary encoder with 6.35mm (¼”) shaft

The RPE1 and RPE2 rotary encoders are available directly from Sinusoid Pty Ltd on their website http://store.sinusoid.com/encoders/encoders-rotary/

Located in Sydney, Australia, Sinusoid Pty Ltd produces electronic parts and software products.

Copyright 2012 Business Wire All Rights Reserved.
